环状螺旋弹簧
Maudlin 现在提供一个环状螺旋弹簧产品系列。环状螺旋弹簧是螺旋圈的延伸或压缩弹簧。可以连接弹簧末端制成弹簧圈和施加径向力。环状螺旋弹通常用于油密封。如果有环状螺旋弹簧需求，请立即联系 Maudlin。
[/two_third]
环状螺旋弹簧标准尺寸
| 产品描述 | 尺寸 | 材质 |
|---|---|---|
| .062 X 4.5" 302 CW PER IP 5430 | .062 X 4.5" | 302 |
| .062 X 6.5" 302 CW PER IP 5430 | .062 X 6.5" | 302 |
| .078 X 12" 302 CW PER IP 5430- | .078 X 12" | 302 |
| .078 X 16" 302 CW PER IP 5430- | .078 X 16" | 302 |
| .078 X 18" 302 CW PER IP 5430- | .078 X 18" | 302 |
| .078 X 3" 302 CW PER IP 5430-1 | .078 X 3" | 302 |
| .078 X 3" 302CW DFAR IP 5430-1 | .078 X 3" | 302 |
| .078 X 4.5" 302 CW PER IP 5430 | .078 X 4.5" | 302 |
| .078 X 6" 302 CW PER IP 5430-1 | .078 X 6" | 302 |
| .078 X 8" 302 CW PER IP 5430-1 | .078 X 8" | 302 |
| .078 X 8" 302CW DFAR IP 5430-1 | .078 X 8" | 302 |
| .103 X 10" 302SS CW PER IP 543 | .103 X 10" | 302 |
| .103 X 12" 302 CW PER IP 5430- | .103 X 12" | 302 |
| .103 X 14" 302 CW PER IP 5430- | .103 X 14" | 302 |
| .103 X 14" 302CW DFAR IP 5430- | .103 X 14" | 302 |
| .103 X 20" 302 CW PER IP 5430- | .103 X 20" | 302 |
| .103 X 24" 302 CW IP 5430-18 | .103 X 24" | 302 |
| .103 X 32" 302 CW PER IP 5430- | .103 X 32" | 302 |
| .103 X 4.5" 302 CW PER IP 5430 | .103 X 4.5" | 302 |
| .103 X 6" 302 CW PER IP 5430-1 | .103 X 6" | 302 |
| .103 X 8" 302 CW PER IP 5430-1 | .103 X 8" | 302 |
| .125 X 10" 302 CW PER IP 5430- | .125 X 10" | 302 |
| .125 X 14" 302 CW PER IP 5430- | .125 X 14" | 302 |
| .125 X 16" 302 CW PER IP 5430- | .125 X 16" | 302 |
| .125 X 18" 302 CW PER IP 5430- | .125 X 18" | 302 |
| .125 X 20" 302 CW PER IP 5430- | .125 X 20" | 302 |
| .125 X 21" 302 CW DFAR IP 5430 | .125 X 21" | 302 |
| .125 X 22" 302 CW PER IP 5430- | .125 X 22" | 302 |
| .125 X 24" 302 PER IP 5430-18 | .125 X 24" | 302 |
| .125 X 26" 302 CW PER IP 5430- | .125 X 26" | 302 |
| .125 X 28" 302 CW PER IP 5430- | .125 X 28" | 302 |
| .125 X 30" 302 CW PER IP 5430- | .125 X 30" | 302 |
| .125 X 36" 302 CW PER IP 5430- | .125 X 36" | 302 |
| .125X40"302CW TE PER IP5430-18 | .125X40"302 | 302 |
| .125X50'302CW PER IP 5430-18 | .125X50" | 302 |
| .197/.047X50'302 CW PER IP5430 | .197/.047X5 | 302 |
| .197X.039X50' 302CW PER IP5430 | .197X.039X50" | 302 |
| .078 X 10" 316 CW PER IP 5430- | .078 X 10" | 316 |
| .078 X 16" 316 CW PER IP 5430- | .078 X 16" | 316 |
| .103 X 14" 316 CW PER IP 5430- | .103 X 14" | 316 |
| .103 X 14" 316 CW DFAR IP 5430 | .103 X 14" | 316 |
| .103 X 16" 316 CW PER IP 5430- | .103 X 16" | 316 |
| .103 X 24" 316 CW IP 5430-18 | .103 X 24" | 316 |
| .103 X 50' 316 PER IP 5430-18 | .103 X 50' | 316 |
| .103 X 8" 316 CW PER IP 5430-1 | .103 X 8" | 316 |
| .125 X 18" 316 CW PER IP 5430- | .125 X 18" | 316 |
| .125X50' CW 316 PER IP 5430-18 | .125X50' CW | 316 |
| .197/.039X50 316 PER IP5430-18 | .197/.039 X 50" | 316 |
| .094X50' OW 302 PER IP 5440-18 | .094X50" | 302 |
| .125X50' OW 302 PER IP 5440-18 | .125X50" | 302 |
| IP5440-18 .012X.053X17.0 316SS | .012 x .053 x 17" | 316 |
| .094X50' OW 316 PER IP 5440-18 | .094X50" | 316 |
| .125X50' 316 OW PER IP 5440-18 | .125X50" | 316 |
| .145X50' 316 OW PER IP 5440-18 | .145X50" | 316 |
| .250X.047 20"316SS OW IP-5440 | .250X.047 X 20" | 316 |
