全面接触弹簧尺寸数据
成形的截面
平型（成形之前）
| 系列号 | A | B | C | D | E | F | J | K | L |
|---|---|---|---|---|---|---|---|---|---|
| -200 | .050" | .050" | .039" | .202" | .280" | .024" | .136" | .014" | .134" |
| -300 | .050" | .050" | .0525" | .312" | .417" | .030" | .190" | .020" | .180" |
| -400 | .050" | .050" | .071" | .377" | .519" | .060" | .231" | .020" | .260" |
| -500 | .050" | .050" | .105" | .495" | .705" | .120" | .285" | .025" | .395" |
